3M FIRE BARRIER SELF-LOCKING PILLOW - 51 x 101 x 228 MM
Self-contained, highly intumescent pillows are designed to firestop a wide variety of through-penetrations including cable trays, conduit and blank openings.
Interlocking strips hold pillows securely together yet release easily for retrofit or reuse – just remove and replace pillows as needed.
- Australian standard testing in accordance with AS1530.4
- International testing in accordance with EN1366 and ASTM E814 (UL Listed)
- Provides up to a 3-hour integrity rating
- No wire mesh reduces safety issues
- Easy to install, easy to remove and reuse
- No cutting and no mess – just lock pillows together, compress and place (use 3M™ Fire Barrier Moldable Putty+ around edges to ensure proper seal)
- No graphite
- Excellent aging properties
- Multiple pillow sizes and ability to field-cut allow for a secure fit in most openings (seal cut edges with polypropylene box sealing tape).
