3M 1183 WIDTH 25 MM IN ROLL OF 16,5 M

3M 1183 COPPER TAPE - 25 MM x 16,5 M

3M 1183 Tape consists of a 1-ounce deadsoft tin-plated copper foil backing and a unique electrically conductive pressure-sensitive acrylic adhesive.

- Deadsoft 1-ounce tin-plated copper foil backing

- Conductive acrylic adhesive

- Supplied on a removable liner for easy handling and diecutting

- Backing : Copper

- Adhesive : Acrylic

- Backing thickness : 0,04 mm

- Total thickness : 0,07 mm

- Adhesion to steel : 3,8 N/10mm

- Breaking strength : 44 N/10mm

- Thermal class : +155 °C

- UL510 recognition

3M 1183 Tape is typically used for applications requiring excellent electrical conductivity from the application substrate through the adhesive to the foil backing.

Common uses include grounding and EMI shielding in equipment, components, shielded rooms, etc.

The tin plating facilitates soldering to the backing and resists oxidation and corrosion.
